Light and agile
Advanced Composite frameset with updated geometry minimises weight and produces a quick, nimble ride quality.
Smooth and comfortable
Innovative D-Fuse composite seatpost absorbs road vibrations, and ergonomic grips keep your hands comfortable on longer rides.
Easy to accessorise
RideSense compatible frame and smart-mount rack and fender system lets you customise the bike for fitness riding, commuting or long-range adventures.
| XS | S | M | ML | L | XL | ||
|---|---|---|---|---|---|---|---|
| A | SEAT TUBE LENGTH (mm) | 430 | 445 | 460 | 490 | 520 | 550 |
| B | SEAT TUBE ANGLE | 73.5° | 73.5° | 73.0° | 73.0° | 72.5° | 72.5° |
| C | TOP TUBE LENGTH (mm) | 540 | 545 | 560 | 575 | 595 | 615 |
| D | HEAD TUBE LENGTH (mm) | 105 | 130 | 155 | 180 | 200 | 225 |
| E | HEAD TUBE ANGLE | 71.0° | 71.5° | 72.0° | 72.0° | 72.5° | 72.5° |
| F | FORK RAKE (mm) | 50 | 50 | 50 | 50 | 50 | 50 |
| G | TRAIL (mm) | 68 | 64.7 | 61.5 | 61.5 | 58.2 | 58.2 |
| H | WHEELBASE (mm) | 1013 | 1014 | 1020 | 1035 | 1045 | 1065 |
| I | CHAIN STAY LENGTH (mm) | 425 | 425 | 425 | 425 | 425 | 425 |
| J | BOTTOM BRACKET DROP (mm) | 70 | 70 | 70 | 70 | 70 | 70 |
| K | STACK (mm) | 511 | 537 | 563 | 586 | 607 | 631 |
| L | REACH (mm) | 388 | 386 | 388 | 395 | 403 | 416 |
| M | STAND OVER HEIGHT (mm) | 681 | 697 | 719 | 741 | 767 | 795 |
| O | STEM LENGTH (mm) | 80 | 90 | 100 | 100 | 110 | 110 |
| P | CRANK LENGTH (mm) | 170 | 170 | 170 | 175 | 175 | 175 |
| Q | WHEEL SIZE | 700C | 700C | 700C | 700C | 700C | 700C |
| Sizes | XS, S, M, ML, L, XL |
| Colour | Metallic Black |
| Frame | ALUXX SL-Grade Aluminum |
| Fork | Advanced-Grade Composite, composite OverDrive steerer |
| Shock | N/A |
| Handlebar | Giant Sport, mini-rise, 31.8 XS:64cm, S:64cm, M:68cm, M/, L:68cm, XL:68cm |
| Grips | Giant ErgoContact |
| Stem | Giant Sports XS:80mm, S:90mm, M:100mm, M/L:100mm, L:110mm, XL:110mm |
| Seatpost | Giant D-Fuse, alloy, 350mm |
| Saddle | Giant ErgoContact |
| Pedals | platform |
| Shifters | Shimano Sora, 2×9 |
| Front Der. | Shimano Sora |
| Rear Der. | Shimano Sora |
| Brakes | Tektro HD-R280, Giant MPH rotors [F]160mm, [R]160mm |
| Brake Levers | Tektro HD-R280 |
| Cassette | Shimano CS-HG201, 11×34 |
| Chain | KMC X9 with Missing Link |
| Crankset | forged alloy, 32/48 XS:170mm, S:170mm, M:170mm, M/L:172.5mm, L:172.5mm, XL: 172.5mm |
| Bottom Bracket | threaded |
| Rims | Giant S-X2 Disc wheelset |
| Hubs | Giant alloy, 12mm thru-axle |
| Spokes | Sapim |
| Tires | Giant Gavia Fondo AR, tubeless, 700x40c |
| Extras | tubeless prepared, 42mm max tire size |
